16ft 12VDC Commercial Waterproof CS35120IP68 LED Strip

SKU:
CS35120IP68
Project Support

Volume discount rates

Below are the available volume discount rates for each individual item when you purchase a certain amount

Buy 10 - 24 and pay only $68.90 each
Buy 25 - 49 and pay only $64.90 each
Buy 50 - 99 and pay only $62.90 each
Buy 100 or above and pay only $61.90 each
$71.90

/ Description

Designed specifically for high-quality exterior/weather-proof linear LED lighting installations, our 12V White CS35120IP68 LED strip allows you to create lasting and headache-free outdoor lighting installations right out of the package. Easily cut, peel, and stick the flexible light tape to your mounting surface using the durable and permanent 3M® adhesive backing. Achieve well over 30,000 hours of useful lighting when used with one of our aluminum profiles for LED strips to draw out the heat and protect the strips from damaging elements. Our CS35120IP68 LED Strip comes with the UL-stamp of approval and is UL-listed for use in both the United States and Canada (cUL). View Spec Sheet Here!

The 12V White CS35120IP68 LED Strip comes in a 16’5” roll/reel and is 0.41” (10.3mm) wide. 3528 LED chips are mounted on a flexible PCB every 0.32” apart. The full LED strip spool has 600 LED packed in a high-density—36 LED/ft (120/M)—configuration. The LED strip comes with (1) 6” 18-2 wire lead with bare, tin-coated ends, for fast and reliable wire-to-wire connections. This LED Strip produces an average of 220 lumens/foot and consumes an average of 2.5 Watts/ft (40 Watts total). Effortlessly cut this LED strip every 0.95” (or every 3 LED chips). The CS35120IP68 LED Strip is IP-68 rated making it suitable for the toughest outdoor environments.

Our 12V White CS35120IP68 LED Strips is well-stocked in a full range of attractive color temperatures from 3000K to 6500K (View our color temperature selection guide), offering unrivaled versatility and adaptability with any look or design. Select Color Temperature under options, by the “Add-to-Cart” button. Medium light output (220 lumens/ft) makes this suitable for landscape lighting, linear overhang lighting, exterior stair-tread lighting, and a wide range of outdoor linear lighting applications.


12V White CS35120IP68 LED Strip Features


  • Highest Quality in LED Strip Lighting at the Best Prices!

  • High Color Rendering! CRI>90

  • UL-Listed (USA AND Canada)

  • Well Stocked, and Ready-to-Ship from Miami, FL

  • High-Density LED Strip Lighting (32/foot or 120/M) Use to make DOTLESS LED Bars!

  • Fully Dimmable with compatible driver/controller.

  • 16'5" roll, easily cuttable every 0.95"

  • Medium Light Output (220 lumens/ft)

  • Consumes 2.5 Watts/ft at 12VDC

  • IP-68 Rated LED Strip Lighting suitable for Outdoor Use, Wet-Rated

  • Dependable and Durable. Backed by our 3-Year Warranty

Quick Specs

Operating Voltage

12VDC

Roll Length

16' 5"

Strip Width

0.41" [10.3mm]

Cut Increments

Every .95"

Power Consumption

2.5 Watts/foot (Average) see full product specs

Lumen Output

220 Lumens/ft

Color Temperatures

3000K, 4500K, 6500K


CS35120IP68 LED Strip Operation


For optimal results and performance, our 12V White CS35120IP68 LED Strip should be installed inside an aluminum profile for LED Strips. We strongly discourage using quick-connectors with this LED strip, soldering is the only way to get a sure-fire, head-ache free connection! Don’t know how to solder? Let us make you UL-listed LED bars with 5-Year Warranty! We’ll also solder leads onto LED strips to any size! View our LED strip instructions here


Best Used with the Following GlowbackLED Products


Aluminum Profiles, Channels, Extrusions for LED Strip Lighting
Most Popular Aluminum Channels for LED Strip Lighting
Aluminum Channels for Surface Mounted Linear LED Strip Lighting
Aluminum Channels for Recessed Mounted Linear LED Strip Lighting
Aluminum Channels for High Output Ultra Bright Linear LED Strip Lighting
Aluminum Channels for Suspended Linear LED Fixtures
Power Supplies: Dimmable, Nondimmable
Connectors
Cables, Wire, Cable Management, Junction Boxes
Brightness Meter
Brightness-Level-3
220 lumens/foot | 2.5 Watts/foot | Suitable for Wet Locations
Project Support
View AllClose

/Product Specs

CS35120IP68 LED Strip Specifications

Make sure to review product specs before purchasing LED strip. Contact-Us for assistance with product specs, application, or installation: 1-800-679-4902 | M-F | 9AM-5PM EST | Sales@bluegateinc.com

Product Code

CS35120IP68XX

Operating Voltage

12VDC

Roll Length

16' 5"

Strip Width

0.41" [10.3mm]

Cut Increments

Every 0.95"

Power Consumption (Full Roll)

31.2 Watts (1.9 Watts/ft)

Power Consumption (3ft Section)

8.4 Watts (2.57 Watts/ft)

Light Output

220 Lumens/ft

Efficacy

85 Lumens/Watt

Available Color Temperatures

3000K (Warm White), 4500K (Natural White), 6500K (Bright White)

Power Feed

6" 18-2 Wire w/ Tin Coated Ends

IP Rating

Suitable for Wet Locations IP68 | Suitable for fully submerged installation

LED Chip

3528

LED Density

36 LEDs/ft (120/M)

Color Rendering

CRI>90

Dimming

Dimmable with any Dimmable LED Driver

Listings

UL-Listed | Class-2

Lifetime

50,000 Hours (Average)

Warranty

3-Year Limited Warranty

BrightnessMeter:
2
Description:
220 lumens/foot | 2.5 Watts/foot | Suitable for Wet Locations
Spec Sheet:
Voltage:
12V
Light Color:
White 2200 - 6000K
Light Output:
Medium
IP-Rating:
Submersible (IP-68)
Listings:
UL-Listed
Color Rendering:
90+ CRI
Applications:
Exterior/Landscape Lighting
Lumen Output:
200 - 300 Lumens/ft
Color Temperature:
3000K
Color Temperature:
4000K
Color Temperature:
6000K
Efficiency:
80 - 90 Lumens/Watt
View AllClose

/Applications

Applications
Cabinet LED Lighting
Showcase LED Lighting
Display LED Lighting
Display Case LED Lighting
Wall-Wash LED Lighting
Wall-Graze LED Lighting
LED Strip Fixtures
Linear LED Fixture
Patio LED Lighting
Boat LED Lighting
Linear LED Lighting
High Output LED Lighting
Art LED Lighting
LED Cove Lighting
LED Museum Lighting
LED Retail Lighting
LED Kitchen Lighting
Outdoor Lighting
Wet-Area LED Lighting
