24V 8W Driver

SKU:
24VMW8W
Project Support
$16.90

/ Description

Our 24V | 8W Hardwired Value LED Driver is a high efficiency, UL listed LED power supply for 24V LED strips, LED bars, LED fixtures, and LED puck lights. Universal input voltage means that it can accept 120-240VAC. This LED driver needs to be "hardwired" to your local electrical code standards. This driver has one 24VDC output that allows you to easily connect up to 8W worth of LED strip lighting. This mini driver easily fits within a standard 4" x 4" junction box.


Features


  • Universal Line-Voltage Input on Small and Compact Unit

  • Easy wire terminals

  • Easily fits in a junction box

Quick Specs

Dimensions

2.3" x 1.2" x 0.9"

Input Voltage

100-277VAC

Output Voltage

24VDC

Output Power

8W (0.34A)

Wiring

Hardwired Connections

Dimming

Non-Dimmable

Environment

Dry/Damp Location

Listings

UL-Listed, Class-2, RoHs


Power Supply Operation


LED Power Supplies convert the source or line voltage of your space to either 12 or 24V DC needed to operate your low-voltage LED strips, LED Bars, or LED Panels. Power Supplies, also known as "LED Drivers" have a rated input voltage and output wattage. We reccomend limiting your load (the sum of the wattage of all the lighting connected) to 80% of the output wattage of the Power Supply. All residences in the US have 110/120VAC line voltage circuits for lighting, but certain commercial spaces have 277VAC lighting circuits. Verify that your Power Supply is rated for 277VAC input voltage if your space requires a 277VAC compatible Power Supply. TRIPLE CHECK YOUR CONNECTIONS before powering up a power-supply, inadertently feeding high voltage to a low-voltage LED strip will cause them to fail. Certian power supplies use the European standard for wire coloring: Brown is Line/"Hot"(Black in US), Blue is Neutral (White in US), and Green/Yellow is Ground (Green in US).


Best Used with the Following GlowbackLED Products


White 2200K - 6500K LED Strips
RGB Color Changing LED Strips
RGBW Color Changing and True White LED Strips
Tunable White LED Strips
O M N I Proffesional LED Controllers
Connectors
Cables, Wire, Cable Management, Junction Boxes
[Copy from Product]
Project Support
View AllClose

/Product Specs

Specifications

Make sure to review product specs before purchasing LED strip. Contact-Us for assistance with product specs, application, or installation: 1-800-679-4902 | M-F | 9AM-5PM EST | Sales@bluegateinc.com

Input Voltage 120-240VAC
Output Voltage 24VDC
Power Output 8 Watts
Output Current 0.33 A
Input Current
at max load
0.05 A @120VAC
Wiring Input: 6" | 18-2 | 120-240VAC
Output: 6" | 16-2 | 12VDC
Dimming Non-Dimmable on Input (no 120VAC dimming): Switched On/Off
Output PWM Dimming (through controller)
IP-Rating 54: Indoor Use Only
Dimensions Length: 3.50"
Width: 1.60"
Height: 1.14"
Listings/Safety UL-Listed
RoHS
FC
Warranty 5-Year Limited Warranty**
Output Voltage:
24VDC
Wattage:
8 -24 Watts
Power Supply Type:
Hardwire with built-in JBOX
IP-Rating:
Dry and Damp Location
Class Rating:
Class-2
Dimming:
Non-Dimmable On/Off
