16ft 24VDC Pro Medium-Output 24VCS06264COBIP67 Waterproof Flexible COB LED Strip

Usually Ships in 24 Hours
Project Support

Volume discount rates

Below are the available volume discount rates for each individual item when you purchase a certain amount

Buy 10 - 24 and pay only $96.90 each
Buy 25 - 49 and pay only $91.90 each
Buy 50 - 99 and pay only $89.90 each
Buy 100 or above and pay only $86.90 each

/ Description

Our NEW 24V White CS06264COBIP67 LED strip, is a high density LED light that features a premium phosphor coating upon the LED chips, creating a completely DOTLESS finish and maximum flexibility that features an IP-67 rating allowing for outdoor use! This flexible LED strip allows one to create lasting and headache-free lighting installations right out of the package, and is perfect for creating custom abstract bendableLED fixtures. Easily cut, peel, and stick the flexible light tape to your desired mounting surface using the durable and permanent 3M® adhesive backing. In order to to draw out the heat and farther protect the your LED strips from damaging elements use our aluminum profiles for LED strips in order to ensure the maximum life capacity of your LED strip. Our 24V White CS06264COBIP67 LED Strip comes with the UL-stamp of approval and is UL-listed for use in both the United States and Canada (cUL). View Spec Sheet Here!

The 24V White CS06264COBIP67 LED Strip comes in a 16’5” roll/reel and is only 0.41” (10.5mm) wide. This strip features our highest density—142 LED/ ft (473/M)— phosphor and silicon coated LED chips mounted on a flexible PCB, allowing for a completely DOTLESS finish in a versatile and durable configuration that makes this strip ideal for creating custom shape and abstract LED fixtures and with an IP-67 Rating it is suitable for use in outdoor applications. The LED strip comes with (1) 6” 18-2 wire lead with bare, tin-coated ends, for fast and reliable wire-to-wire connections. This LED Strip produces an average of 370 lumens/foot and consumes an average of 3.7 Watts/ft (59 Watts total). Effortlessly cut this LED strip every 1.79”. View Spec Sheet Here!

24V White CS06264COBIP67 LED Strip Features

  • Highest Quality in LED Strip Lighting at the Best Prices!

  • NEW Highest Density LED Strip

  • Achieve DOTLESS Lighting in channel of ANY depth

  • High Color Rendering! CRI>90

  • UL-Listed (USA AND Canada)

  • Well Stocked, and Ready-to-Ship from Miami, FL

  • IP-67 Rated for Outdoor Use!

  • Fully Dimmable with compatible driver/controller.

  • 16'5" roll, easily cuttable every 1.79"

  • Medium Light Output (370 lumens/ft)

  • Consumes 3.7 Watts/ft at 24VDC

  • Dependable and Durable. Backed by our 3-Year Warranty

Quick Specs

Operating Voltage


Roll Length

16' 5"

Strip Width

0.41" [10.5mm]

Strip Height

0.16" [4mm]

Cut Increments

Every 1.79"

Power Consumption

3.7 Watts/foot (Average) see full product specs

Lumen Output

370 Lumens/ft


IP-67 Suitable for Outdoor Use

Color Temperatures

2700K, 3000K, 4000K, 6500K

24VCS06264COBIP67 LED Strip Operation

For optimal results and performance, our 24V White CS06264COBIP67 LED Strip should be installed inside an aluminum profile for LED Strips. We strongly discourage using quick-connectors with this LED strip, soldering is the only way to get a sure-fire, head-ache free connection! Don’t know how to solder? Let us make you UL-listed LED bars with 5-Year Warranty! We’ll also solder leads onto LED strips to any size! View our LED strip instructions here

Best Used with the Following GlowbackLED Products

Aluminum Profiles, Channels, Extrusions for LED Strip Lighting
Most Popular Aluminum Channels for LED Strip Lighting
Aluminum Channels for Surface Mounted Linear LED Strip Lighting
Aluminum Channels for Recessed Mounted Linear LED Strip Lighting
Aluminum Channels for High Output Ultra Bright Linear LED Strip Lighting
Aluminum Channels for Suspended Linear LED Fixtures
Power Supplies: Dimmable, Nondimmable
Cables, Wire, Cable Management, Junction Boxes
[Copy from Product]
Project Support
View AllClose

/Product Specs

24VCS06264COBIP67 LED Strip Specifications

Make sure to review product specs before purchasing LED strip. Contact-Us for assistance with product specs, application, or installation: 1-800-679-4902 | M-F | 9AM-5PM EST | Sales@bluegateinc.com

Product Code


Operating Voltage


Roll Length

16' 5"

Strip Width

0.41" [10.5mm]

Strip Height

0.16" [4mm]

Cut Increments

Every 1.79"

Power Consumption (Full Roll)

59 Watts (3.7 Watts/ft)

Power Consumption (3ft Section)

11 Watts (3.7 Watts/ft)

Light Output

370 Lumens/ft


100 Lumens/Watt

Available Color Temperatures

2700K (Incandescent White), 3000K (Warm White), 4000K (Natural White), 6500K (Bright White)

Power Feed

6" 18-2 Wire w/ Tin Coated Ends

IP Rating

IP67 Rated for Outdoor Use

LED Chip


LED Density

142 LEDs/ft (473/M)

Color Rendering



Dimmable with any Dimmable LED Driver


50,000 Hours (Average)


3-Year Limited Warranty

Spec Sheet:
Light Color:
White 2200 - 6000K
Light Output:
Medium High
Suitable for Outdoor Use (IP-65 or IP-67)
Color Rendering:
90+ CRI
Exterior/Landscape Lighting
Special Features:
Lumen Output:
301 - 500 Lumens/ft
Color Temperature:
Color Temperature:
Color Temperature:
Color Temperature:
91 - 100 Lumens/Watt
