Aluminum Profile "J" 8 ft (94")

SKU:
ALUMJF-94
Availability:
Usually Ships in 24 Hours
Project Support Dotless LED fixtures
Due to new shipping size restrictions, 94" is the MAX size for free shipping. You can select full-size 8ft (96 Inch) before adding to your cart, but will be charged with a FEDEX OVERSIZE fee at checkout.

Volume discount rates

Below are the available volume discount rates for each individual item when you purchase a certain amount

Buy 10 - 24 and pay only $27.46 each
Buy 25 - 49 and pay only $26.01 each
Buy 50 - 99 and pay only $25.29 each
Buy 100 or above and pay only $24.57 each
$28.90

/ Description

A perfect low-profile solution for under-cabinet, shelf, and closet lighting applications, our Aluminum Profile “ J” is our thinnest aluminum extrusion for LED strips, at just slightly over ¼” (0.28”) thick. Made of premium aluminum alloy, Aluminum Profile "J" draws the heat out of your LED strips to maximize their longevity. A universal housing for LED tape! Aluminum Profile “J” can accommodate any water-proof or non-waterproof LED strip up to 12mm (0.40”) wide. Use with our 24V High Density 240/m LED Strip in order to achieve dotless lighting. Aluminum Profile “J” is conveniently sold in 8ft lengths as a completed kit including a pair of endcaps, mounting clips, and one premium polycarbonate, UV-resistant frosted lens View Spec Sheet Here!


Features


  • Slim, low-profile design, for discreet linear LED lighting applications

  • Easily concealable

  • Smooth, Diffused light with PC frosted lens.

  • Increases Lifetime of any LED Strip through heat dissipation

  • Fast, headache-free clip mounting system.

  • Protects LED Strips from water and elements.

  • Reliable Aluminum Housing for LEDs

  • Well-Stocked and ready to ship from Miami, FL.

Quick Specs

Length

8' (Actual Size 94", 96" available w/ shipping surcharge)

Width

0.67"

Height

0.31"

Lens

Frosted

Max Light Output

Medium (4 Watts/ft)

Max Strip Width

0.48" (12mm)


Applications

The slim and low profile of this channel makes it a perfect solution for under-cabinet, over-cabinet, and in-cabinet linear LED lighting. Perfectly suited for discreet linear shelf lighting and display cases. Aluminum Profile "J" is also popular for cove lighting applications. Use Aluminum Profile "J" to protect LED strips from water and the elements.

Installation

Install in minutes with easy snap-and-go clips. This Aluminum housing comes with (3) mounting clips. Simply install clips onto your desired surface with screws and quickly snap your LED aluminum housing into place.


Cutting

To cut your aluminum profiles and make your lighting fixtures a custom length, simply snap the lens onto the profile, and place the channel onto a miter saw with the lens facing down. By doing this you can easily cut both the channel and lens to your desired length at the same time. We recommend using a NEW fine tooth blade to cut your aluminum channels for LED strips. The diffuser/lens is fragile and will easily break with an old blade. The easiest way to avoid breaking a lens or diffuser is to lower the saw blade slowly while cutting.


DOTLESS Lighting!

To achieve dot-free evenly diffused lighting in Aluminum Profile "J" choose from the following DOTLESS LED strips.
12V DOTLESS White LED Strip (Most Popular!)
24V DOTLESS White LED Strip


Best Used with the Following GlowbackLED Products


Extra Pair of Endcaps for Aluminum Profile J
Extra Lens/Diffuser for Aluminum Profile J
Extra Mounting Clips for Aluminum Profile J
UL-Listed White LED Strips
RGB Color Changing LED Strips
RGBW Color Changing and White LED Strips
Dimmable and Nondimmable Power Supplies
Connectors
Project Support Dotless LED fixtures
Due to new shipping size restrictions, 94" is the MAX size for free shipping. 96" housings are available upon request with a shipping surcharge. Contact-Us Today for more information
Project Support Dotless LED fixtures
Due to new shipping size restrictions, 94" is the MAX size for free shipping. You can select full-size 8ft (96 Inch) before adding to your cart, but will be charged with a FEDEX OVERSIZE fee at checkout.
View AllClose

/Product Specs

Specifications

Make sure to review product specs before purchasing LED strip. Contact-Us for assistance with product specs, application, or installation: 1-800-679-4902 | M-F | 9AM-5PM EST | Sales@bluegateinc.com

Length 8' (Actual Size 94", 96" available with shipping surcharge)
Width 0.69" (0.98" w/ flange)
Height 0.59"
Lens Frosted
Max Light Output Medium (4 Watts/ft)
Max Strip Width 0.47" (12mm)
short-desc-sec:

8ft | 0.67" W x 0.31" H

Spec Sheet:
Mount Type:
Surface Mount
Suggested MAX Wattage:
4 Watts/ft
Light Output:
Medium
MAX LED Strip Width:
12mm
Profile Width:
0.5 - 0.75 Inch
Profile Height:
under 0.40 Inch
Profile Length:
8ft
Applications:
Cabinet Lighting
Applications:
Cove Lighting
Applications:
Decorative/Accent Lighting
Special Features:
Slim Low Profile Design
